GUIA S&S 45 ‘ sloop – 1970 – 148.000 € a piece of Italian yachting history



2024 Video and pics are available as updated spec.



History of the Whitbread: Download PDF>>

Very interesting and rare old pictures during Whitbread at the bottom of this article

Possibility to be protected by Italian Ministry “Beni cuturali” for future benefits

GUIA 45 ‘ sloop

year 1970

buider Craglietto

designer S&S

loa 45 ‘-13.9 mt

lwl 33′- 10.2 mt

beam 12′- 3.9 mt

keel fin and skeg

draft 33’- 2.2 mt

displ. about 12 t

engine: Nissan 65 hp marinized 2002

construction: mahogany planking on laminated oak frames.

History: Guia participated in the first Whitbread Round the World Race in 1973 finishing 5^th individually – and the Italians winning as a team. Trophies from this, the Cape Town to Rio race of 1971 and others are kept in and belong to the boat.

Access below can be either from the cockpit to the owner’s cabin aft or through the coachroof hatch directly into the saloon. The beams, deck head, bulkheads and furniture are ofvarnished mahogany, the cabin sole of varnished holly and teak, overall combiningelegance, ambience, and warmth with practicality. The elegant mottled coral upholsteryitems, renewed a year ago are also protected by removable green covers. From the cockpit via a sliding hatch and steps down you enter in the owner’s cabin with asingle berth each side and an en suite head compartment with folding basin, Blake WCand shower forward to starboard. A hanging locker is forward to port and stowage is indrawers below and spaces outboard the berths. Two opening ports provide goodventilation.
Moving forward past the main head (also with Blake WC and accessible to both cabins)you access the main cabin with a chart table and navigation area to port and a large galleystarboard. The galley has a double sink, 2 burner hob with oven and a huge and very wellinsulated stainless steel fridge. Access to this area can also be through the main slidinghatch over the coach roof and companionway steps down.
Forward and a further step down is the saloon with settee berths either side and another
single berth above and outboard to port. To starboard are two lockers with a book shelf
between. Amidships is a mahogany drop leaf dining table.
The forepeak had two lifting pipe cot berths with stowage below and outboard. The
starboard pipe cot, while available has been removed and lockers and drawers built in.
The foc’sle contains the very substantial chain locker. Ventilation is by hatches and
opening ports by the galley, chart table and heads.
– New diesel Webasto air heating recently installed.
– 100 litre fridge (engine driven compressor)
– Mattresses and blankets; two for each berth

“La storia di quest’imbarcazione, su progetto Sparkman & Stephens, sarà sempre legata a quella dell’imprenditore milanese dell’acciaio Giorgio Falck, appassionato velista scomparso nel 2004, che ne commissionò la costruzione.
La barca ha partecipato alla prima Whitbread del 1973, il giro del mondo in regata, classificandosi al quinto posto di flotta e prima delle italiane.
Poi, affidata allo skipper Luciano Ladavas, ha compiuto un altro giro del mondo durato cinque anni.
Un successivo proprietario l’ha tenuta fino al 1999, momento in cui è stata acquistata da uno spagnolo.
Guia, gemella di Mabelle, è costruita in fasciame di mogano sovrapposto su ordinate di quercia bianca.” ( NR)

ANNO 1970
CANTIERE MARIANO CRAGLIETTO (TRIESTE – ITALY)
PROGETTO SPARKMAN & STEPHENS (NY – USA)
LUNGHEZZA F.T. 13,89 m
LUNG. AL GALLEGGIAMENTO 10 m
LARGHEZZA 3,90 m
PESCAGGIO 2,10 m
DISLOCAMENTO 12 tons
SUPERFICIE VELICA 90 m²



AGGIORNAMENTI AL 2024

SOME DATA FROM THE INVOICES

MULTIFUNCTION DISPLAY B&G VULCAN 9 NO XDCR

WIND SENSOR 608

SIMNET MAST CABLE

RADAR ANTENNA SIMRAD HALO20

RADAR SUPPORT

TRITON DIGITAL DISPLAY

B60 AIRMAR BRONZE TRANSDUCER BRONZE 12º HULL PENETRATOR

NMEA 2000 BASIC NETWORK KIT

LOWRANCE SIMNET TO NMEA 2000 ADAPTER

NMEA 2000 MICRO-C

NAVIONICS CHART

WALKY VHF ICOM IC-M25

WINDEX VANE TYPE MODEL 15 380 MM

AT10 NMEA 24715 UNIVERSAL CONVERTER

VICTRON ENERGY ORION DC-DC CONVERTER DC-DC IP67 12/24 NT-1207

BLUE SMART 12/30 (3) IP22 BLUETOOTH CHARGER

– THE ENTIRE ELECTRICAL SYSTEM WAS REPLACED AND THE WIRING FROM TWO PREVIOUS UNUSABLE INSTALLATIONS WAS REMOVED. THE PLUMBING WAS ALSO RENOVATED.

-AS MENTIONED, THE FORWARD CABIN HAS BEEN FITTED OUT FOR SLEEPING.

-THE DEAD AND LIVE WORK HAS BEEN REPAIRED, TIMBERS REPLACED, JOINTS CAULKED AND ALTHOUGH IT WAS SANDED AND PAINTED LAST YEAR AND VARNISHED THIS YEAR, THIS IS STILL TO BE IMPROVED BECAUSE IT NEEDS TO BE GIVEN SEVERAL COATS.

-BILGE PUMP WITH AUTOMATIC.

ITT WATER PUPPY 24 V WP2000 PUMP.

REPAIR DIMAMOS MOTOR.



-THE SCREWS HAVE BEEN REMOVED FROM THE CANDLESTICKS AND SEALED AS WELL AS THE DECK FITTINGS. SEALED THE DECK SEAMS, SANDED THE DECK AND REMOVED THE LEAKS EXCEPT IN THE AFT CABIN WHERE THE WINCHERS NEED TO BE RAISED AND SEALED.

-NEW GENOA FURLING SYSTEM (FURLEX 404S WITH 12MM STAY INCLUDED UP TO 20M AND TENSIONER WITH STA-LOK PRESSING END) AND REEFED SEVERAL SAILS.

2 HIGH SHROUDS.

LAZY BAG WITH BUILT-IN AWNINGS.

LACY JACKS WITH PULLEYS.

A STERN AWNING HAS ALSO BEEN MADE WHICH IS UNUSED BECAUSE WE GOT IT AT THE END OF AUGUST BUT THE BAR IS NEW AND HAS BEEN REMOVED.

-THE GALLEY IS NEW AND THE OVEN HAS BEEN REMOVED AND A CUPBOARD FITTED IN ITS PLACE; HOLES IN THE INTERIOR HAVE BEEN FILLED (I DON’T KNOW IF THEY WERE FOR SPEAKERS OR WHAT) AND GLASS HAS BEEN FITTED IN THE SALOON CUPBOARDS.

– THE BOW MATTRESSES AND THE TWO STERN MATTRESSES WERE REPLACED. THE SALOON MATTRESSES WERE REUPHOLSTERED AND THE THREE COCKPIT MATTRESSES WERE REUPHOLSTERED.

-ONE OF THE BATHROOMS WAS DISABLED AND SHELVES HAVE BEEN PLACED AS A WARDROBE TO STORE WAISTCOATS, SAILS…LEAVING ONLY ONE BATHROOM, ALTHOUGH THE OTHER ONE COULD EASILY BE RECOVERED (I KEEP THE SINK AND THE TOILET).



-THE DECK WAS REPAIRED IN NOV 2022.
